400w 600w 1000w LED Stadium Light Sports Lighting Projection Light High Pole Light Projection Light Floodlight
Item NO.
Power
Size
Beam Angle
LED
Voltage
Luminous Flux
CRI
Warranty
WS-STD04-400
400w
395*375*165
10/20/30/60/90
SMD3030 480pcs
AC 85-265V
120-150lm/w
80
5 years
WS-STD04-600
600w
515*375*165
10/20/30/60/90
SMD3030 720pcs
AC 85-265V
120-150lm/w
80
5 years
WS-STD04-1000
1000w
575*475*165
10/20/30/60/90
SMD3030 1260pcs
AC 85-265V
120-150lm/w
80
5 years
Specifications:
Voltage AC85-265V
LED Qty SMD3030 520pcs each module,each module 500w
Power 400w 600w 1000w
Body material : fins type Aluminum
Beam angle:20/30/60/90
LED colour RGB/red/blue/green/warm white/white
IP 65
Shot distance:more than 200m
Features:
Top Standard CREE or Lumileds LEDs
• Lamp Efficacy >150lm/W
• Multi-optional Optical Lenses for the optimized lighting performance
• 125,000 hours life
• > 80Ra
High Thickness Die Casting Aluminum Modular Heat Sinks
• High Thickness Modular Aluminum for Better Heat Dissipation
• Modular Design with Air Flow to Reduce Temperature
• Wide Power Range
Anti-glare Reflectors
• Help to improve for a comfortable environment
• Friendly for eyes to improve sports performance
• A more comfortable environment can Improve audience experience
Rotating Brackets
• High strength brackets
• Rotating design
• With target angle marks
Compact Design with IK10 Impact Resistant
• Compact and modern design
• 1-4 modules upto 2000 watts
• High transparent PC optical lenses for a high grade shock and impact resistance
400w 600w 1000w LED Stadium Light Sports Lighting Projection Light High Pole Light Projection Light Floodlight
| Item NO. | Power | Size | Beam Angle | LED | Voltage | Luminous Flux | CRI | Warranty |
|
WS-STD04-400 |
400w |
395*375*165 |
10/20/30/60/90 | SMD3030 480pcs |
AC 85-265V |
120-150lm/w |
80 |
5 years |
|
WS-STD04-600 |
600w | 515*375*165 |
10/20/30/60/90 |
SMD3030 720pcs |
AC 85-265V |
120-150lm/w |
80 |
5 years |
|
WS-STD04-1000 |
1000w | 575*475*165 |
10/20/30/60/90 |
SMD3030 1260pcs |
AC 85-265V |
120-150lm/w |
80 |
5 years |
Specifications:
LED Qty SMD3030 520pcs each module,each module 500w
Power 400w 600w 1000w
Body material : fins type Aluminum
Beam angle:20/30/60/90
LED colour RGB/red/blue/green/warm white/white
IP 65
Shot distance:more than 200m
Features:
Top Standard CREE or Lumileds LEDs
• Lamp Efficacy >150lm/W
• Multi-optional Optical Lenses for the optimized lighting performance
• 125,000 hours life
• > 80Ra
High Thickness Die Casting Aluminum Modular Heat Sinks
• High Thickness Modular Aluminum for Better Heat Dissipation
• Modular Design with Air Flow to Reduce Temperature
• Wide Power Range
Anti-glare Reflectors
• Help to improve for a comfortable environment
• Friendly for eyes to improve sports performance
• A more comfortable environment can Improve audience experience
Rotating Brackets
• High strength brackets
• Rotating design
• With target angle marks
Compact Design with IK10 Impact Resistant
• Compact and modern design
• 1-4 modules upto 2000 watts
• High transparent PC optical lenses for a high grade shock and impact resistance
